School Not Fade Rubber Running Track Shock Absorption Anti Spikes
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Vertical Deformation | 1.47mm | Anti-slide Value(bpn 20℃) | 47 |
|---|---|---|---|
| Tensile Stength,mpa | 1.11 | Elongation At Break,% | 138.5 |
| Fire Resistance Level | Level1 | Shock Absorption,% | 35 |
| Thickness | 13 | Color | Red |
| Application | Gymnasiums,school | Feature | High Rebound,waterproof And Soundproof |
| High Light | School Not Fade Rubber Running Track,Anti Spikes Rubber Running Track,Shock Absorption Synthetic Running Track |
||
Product Description
School Rubber Running Track ,Not fade And Waterproof,Soundproof And Anti-spikes
Product Description
Excellent performance
It's a design based on human kinetics and physical characteristics flooring system, with hard top layer combined with soft rebound cushion lower layer structure. It's suitable to lay on concrete or asphalt substrates. The cushion layer is formed by single component modified polyurethane and top up with two-component modified acrylic resilience layer
| No. | Test project | Standard requirements |
CN-S05F | CN-S05T | CN-S05H | CN-S05Z | Judge |
| 1 | Shock absorption rate,% | 30-50 | 38.9 | 39.2 | 39.3 | 40.1 | Qualified |
| 2 | Vertical deformation,mm | 0.6-2.5 | 1.74 | 2.02 | 2.40 | 2.4 | Qualified |
| 3 | Anti-slide value,BPN20℃≥ | 47 | 57 | 57 | 56 | 57 | Qualified |
| 4 | Tensile strength,Mpa ≥ | 0.5/0.4 permeable type | 0.8 | 0.4 | 0.62 | 0.51 | Qualified |
| 5 | Tensile elongation,% ≥ | 40 | 76.7 | 46 | 54.3 | 52.8 | Qualified |
| 6 | Flame retardant level | I | I | I | I | I | Qualified |
| 7 | Thickness,mm | 13 | 13.1 | 13.0 | 13.1 | 13.0 | Qualified |
| No. | Test project | Standard requirements |
CN-S05F | CN-S05T | CN-S05H | CN-S05Z | Judge |
| 1 | Benzene,g/kg ≤ | 0.05 | nought | nought | nought | nought | Qualified |
| 2 | BTX,g/kg ≤ | 0.05 | nought | nought | nought | nought | Qualified |
| 3 | Toluene diisocyanate,% ≤ | 0.2 | nought | nought | nought | nought | Qualified |
| 4 | Soluble heavy metal,mg/kg Pb ≤ | 90 | nought | nought | nought | nought | Qualified |
| 5 | Soluble heavy metal,mg/kg Cd ≤ | 10 | 2.4 | 2.0 | 1.9 | 2.8 | Qualified |
| 6 | Soluble heavy metal,mg/kg Cr ≤ | 10 | 3.2 | 3.1 | 3.4 | 3.4 | Qualified |
| 7 | Soluble heavy metal,mg/kg Hg ≤ | 2 | nought | nought | nought | nought | Qualified |
Advantages
1. Color EPDM surface, making it highly resistant to ultraviolet rays, no fade, strong wear,which are proved
2. The EPDM granules don't drop, mix the EPDM with polyurethane binder first,and then construct by mechanical spraying.
3. Excellent weather resistance, not aging.
4. Stable Elasticity all year around, so in winter is not hard and in summer it is not soft.
5:effecient buffer rebound
6:durable performance
7:truly healthy and environmental protection
8:construction is simple and convenient.
9:high wear-resistant and anti-spike
High strength and high weather resistance polyurea material ,water absorption and solidification ,super wear-resistance,anti-spike,don’t fall off.
10:bright and durable
Under the action of high anti ultraviolet performance ,the unique locking factor is stronger and more durable.
11:high UV resistance
The inherent anti ultraviolet particles double increase the anti-aging performance of the runway and prolong the service life of the runway.
12:no toxicity and no smell
Does not contain “Mocha”,chlorinated paraffin ,heavy metals and other carcinogenic substances,evironmental protection formula non-toxic tasteless.
139:water resistant and weather resistant
Since called “Universal paint”,the polyurea materials have excellent performance of water drought ,to ensure the runway’s quality lasting of stability.
14:high bond and high ductility.
More than the bond strength of 2MPa,and more than doubled the elongation,ensure no delamination,no crack.
FAQ
Q1: Are you manufacturer or trader?
We have two major production bases,one in Nanjing and the other in JiangMen,and the laying area of our materials is more than ten million square meters per year.
Q2: What is the advantage of your factory? Why should I choose you?
Our products are odorless and non-toxic;
We have two main production bases and can make every kinds of SPU venues, running track,artificial grass,sports flooring construction and colloidal particles;
Q3: What kind of certificate you have?
We have certificate of RoHS,ISSS,CE,ITF2,ITF5,IFFF, ISO9001 and ISO14001,SGS, ASG,etc and can export our products all over the world.
Q4: What is guarantee time of your products?
5 years
