Super Wear-Resistance and Anti-spike ,Not fall off Silicon Polyurea Basketball Court Flooring
| Place of Origin | China |
|---|---|
| Brand Name | CN Sports |
| Certification | IAAF/ITF/RoHS/ISO140019001/ISO14001/ISSS |
| Model Number | CN-S01 |
| Minimum Order Quantity | / |
| Price | US$10-35/square meter |
| Packaging Details | Pack in barrel/pallet |
| Delivery Time | Within 15 work days after your deposit |
| Payment Terms | L/C, T/T |
| Supply Ability | 100000Tons per year |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Material | Silicon Polyurea | Color | Red Or You Can Customize |
|---|---|---|---|
| Warranty | 8-10years | Function | Anti-slid And High Rebound And Soundproof |
| Thickness | 5mm Or You Can Customize | Flame Retardant Level | Level1 |
| Vertical Deformation | 0.9mm |
Product Description
Super Wear-Resistance and Anti-spike ,Not fall off Silicon Polyurea Basketball Court Flooring
Product Description
What is SPU?
SPU sports flooring is made by silicon PU / silicon polyurethane materials. It has been implemented for the past 10 years and created a classic name for sports flooring. It is widely used for sports flooring and playground field, especially for outdoor fields.
It’s a design based on human kinetics and physical characteristics flooring system, with hard top layer
combined with soft rebound cushion lower layer structure. It’s suitable to lay on concrete or asphalt
substrates. The cushion layer is formed by single component modified polyurethane and top up with two
component modified acrylic resilience layer.
The excellent performance of SPU:HARD TOP SOFT DOWN
The purpose of building sports courts is to ensure a professional,safe,healthy sports condition-the characteristicsof hardness will bring the professional sporting feeling;the cushion effectively increasing the shock absorption and reduce the incidence of injuries to ankles, joints and ligaments. At the same time,it should reduce abrasion caused by falling and accident
Detailed specification of product
1) Standard of Sports Performance
| Item | test project | technical requirements | test results |
| 1 | Shock absorption rate (%) | Fr≥12 | 21 |
| 2 | The springback value(%) | ≥20 | 30 |
| 3 | Sliding friction coefficient | 0.4≤u≤0.7 | 0.53 |
| 4 | Compression recovery rate(%) | ≥95 | 97 |
| 5 | Hardness(Shore A),20℃ | 60-80 | 68 |
| Item | test project | technical requirements | test results | |
| 1 | Volatile organic compounds(VOC)(g/L) | ≤670 | 91 | |
| 2 | benzene(%) | ≤0.3 | Did not check out | |
| 3 | Toluene ＋xylene＋ ethyl benzene(%) | ≤30 | 5 | |
| 4 | The free diisocyanate(TDI＋HDI)(%) | ≤0.4 | Did not check out | |
| 5 | Halogenated hydrocarbon(%) | ≤0.1 | Did not check out | |
| 6 |
Soluble heavy metals(mg/kg) |
plumbum Pb | ≤90 | Did not check out |
| Cadmium Cd | ≤75 | Did not check out | ||
| chromium Cr | ≤60 | Did not check out | ||
| mercury Hg | ≤60 | Did not check out | ||
2) Technical data for SPU Sports Flooring
| Item | test project | technical requirements | test results | |
| 1 | Tensile elogation,% | ≥400 | 1112 | |
| 2 | The tensile strength,Mpa | ≥1.8 | 3.5 | |
| 3 | Artificial climate ageing resistance(300h) No bubbles, no peeling, no crack； | pulverization≤grade 1,△E≤6.0 | No bubbles, no peeling, no crack； pulverization＝grade 0,△E＝0.57 | |
| 4 | Wear resistance(750g/500r),g | ≤0.050 | 0.031 | |
| 5 | Durability, aging experiment(168h) | Tensile elongation,% | ≥300 | 853 |
| The tensile strength,Mpa | ≥1.3 | 1.6 | ||
| 6 |
Resistance to water(168h)
|
No bubbles, no peeling, allowing a slight color change,recovery after 2h | No bubbles, no peeling, no discoloration | |
| 7 | Flame retardant level | I | I | |
- Environmental Performance Standard
Based on considerations of social environmental security responsibility; Perform interior decoration decorate material national mandatory standard, do real non-toxic harmless green material.
- Durable Performance Standard
Based on the owner or operator, construction and maintenance; Reflect the quality level of the site, and durable time limit
Our advantages (Why choose us?)
1. 1. Our products are odorless and non-toxic.
2. We have two main production bases and can make every kinds of SPU venues, running track, artificial grass, sports flooring construction and colloidal particles.
3. 3. We have more than 20 years' development and production history.
4. 4. Exceed ten million squre meters every year in the world.
OUR TRAINNING AND SERVICES:
- Provide construction guidance process text information
- Provide construction process video
- Can send person to our factory for training and studying
- We can also arrange the engineer to the site for training and guidance
- 24hours of telephone consultation service
- Regular understanding the situation of the site usage
Product Structure:
Project Case
R&D:
FAQ:
1. Are you manufacturer or trader?
We have two major production bases,one in Nanjing and the other in JiangMen,and the laying area of our materials is more than ten million square meters per year. For all the products we produce by ourselves and with our own logo. Welcome to visit our factories if interested.
2. What kind of certificate you have?
We have certificate of RoHS,ISSS,CE,ITF2,ITF5,IFFF, IAAF, ISO9001 and ISO14001,SGS, ASG,etc and can export our products all over the world.
3.Is your products safe and enviroment friendly?
Yes, our products are safe and quality assured. It is Eco-friendly and harmless.
